CMZ TL20 CNC Lathe
CMZ TL20 CNC Lathe
Perfect machine. It just had a service done by CMZ. It can be seen at work at its current location. Interesting price.
Data Sheet
| YEAR | 2001 |
| DISTANCE BETWEEN SPINDLE NOSE | mm. 640 |
| ROTATING DIAMETER (max) | mm. 685 |
| TURNING DIAMETER (max) | mm. 400 |
| MAIN SPINDLE | |
| SPINDLE NOSE (ASA attachment) | Asa A2-6 |
| SPINDLE SPEED (min./max.) | g./min. 4.000 |
| POWER OF THE SPINDLE ENGINE (kW) | Kw. 15/22 |
| BAR PASSAGE | / |
| COUNTERSPINDLE: | |
| SPINDLE NOSE (ASA attachment) | / |
| SPINDLE SPEED (min./max.) | / |
| POWER OF THE SPINDLE ENGINE (kW) | / |
| BAR PASSAGE | / |
| NUMBER OF UPPER TURRETS | 1 |
| NUMBER OF LOWER TURRETS | / |
| X SLIDE TRAVEL | / |
| Z SLIDE TRAVEL | / |
| Y SLIDE TRAVEL | / |
| X2 SLIDE TRAVEL | / |
| Z2 SLIDE TRAVEL | / |
| Y2 SLIDE TRAVEL | / |
| X3 SLIDE TRAVEL | / |
| Z3 SLIDE TRAVEL | / |
| Y3 SLIDE TRAVEL | / |
| RAPID FEEDS | / |
| TOOL TURRET (Model) | CMZ |
| NUMBER OF TOOL POSITIONS: | |
| T1 | 12 |
| T2 | / |
| T3 | / |
| CONTROL | Fanuc 21i-TA |
| DIMENSIONS L P H | / |
| WEIGHT | |
| ACCESSORIES INCLUDED | |
| NOTES | Works carried out by CMZ on request of the end user: February 2020 - replaced X-axis bearings, spindle and turret geometries control and realignment, presetting control, replaced oil separators for lubricant of the jude, replaced switchboard relay for turret and drive batteries, replaced control unit and overhauled the hydraulic system. We include an already paid maintenance contract with CMZ of € 2.500,00 valid for one year (from June 2020 until June 2021) including the visit of a technician for one day for ordinary maintenance. Belt chip extractor, manual tool setter, no self-centering, automatic door opening with cod.M, hydraulic tailstock. |
All technical data are indicative, may be changed without notice and refer to the standard conditions of the new good. The second-hand good may not have the same performance as the new one.
