BCM CNC deep hole drilling machine Model SMALL
BCM CNC deep hole drilling machine Model SMALL
ConGri Macchine Utensili offers a new BCM drilling machine model Small. The machine is brand new and we sell it at really special price (2022 – Newly manufactured machine). Contact us for information.
Technical Datasheet
| YEAR | 2022 Newly manufactured machine |
| X AXIS COURSE | (Table) mm. 800 |
| VERTICAL TRAVEL Y | mm. 350 |
| Z AXIS TRAVEL | mm. 300 |
| DRILLING STROKE | mm. 915 |
| MINIMUM HOLE DIAMETER | mm. 5 |
| MAXIMUM HOLE DIAMETER | mm. 25 |
| MANDRIN | |
| SPINDLE SPEED MIN./MAX | Max 7.000 RPM |
| SPINDLE POWER IN KW/MAX | Kw. 5.5 with pressure at 90 Bar |
| LUBRICANT | Full oil or emulsion |
| PALLET SIZE | mm. 800 X 800 |
| ROTATION | N. 360.000 positions |
| MAX. PERMISSIBLE LOAD | Kg. 2.500 |
| CONTROL | FAGOR CNC |
| OVERALL DIMENSIONS | Lenght mm. 4.730 X Depth mm. 4.670 X Height mm. 2.300 |
| ACCESSORIES | Coolant system with paper filter / Integrated chip conveyor / Connectivity package 4.0 ready / |
All technical data shown are indicative, may be changed without notice and refer to the standard condition of new goods. Used goods may not have the same performance as new.
